METALWORKS Linear - Classics

METALWORKS Linear - Classics

Durable, metal planks in more widths for a variety of flexible and unique acoustical interior/exterior solutions.

Cleaning & Disinfecting

NRC (Noise Reduction Coefficient) is a standard measurement for a material’s acoustical absorption ranging from 0.00 (no absorption) to 1.00 (total absorption).

CAC (Ceiling Attenuation Class) is a standard measurement of a ceiling system’s ability to block sound between two closed spaces. CAC values of 35 or greater are recommended to achieve speech privacy.

NIC (Noise Isolation Class) is a standard measurement of total sound attenuation between two closed spaces. It considers the ceiling, wall, and other interior finishes.

AC (Articulation Class) is a standard measurement of a ceiling system’s ability to attenuate sound within a large open plan space. AC values of 170 or more are recommended to reduce speech distraction.

Sabin is the unit of measure for total sound absorption of an acoustical object (like blades, baffles, clouds, and canopies).

Now, standard products available in 4 weeks or less provide a variety of options and offer short lead times to fit most budgets. Standard sizes and colors mean no shop drawings or submittal sample approvals. Package with the diverse portfolio of Armstrong solutions.

Want to learn more? Check out the FAST Program for Specialty Ceilings.

Performance

  • Now available in 17 standard Effects finishes for both interior and exterior applications
  • Nominal 2", 4", 6", 8", 10", and 12" wide planks, including nominal 1" reveal (contact ASQuote for custom capabilities at asquote@armstrongceilings.com)
  • Standard planks in WH, SG, and MY finishes included in FAST3 program – ship from manufacturer to location in 3 weeks or less*
  • CLEANASSURE family of products – includes disinfectable planks, suspension systems, and trim
  • Discontinuous ceilings possible with Effects trim or AXIOM trim, using the Adjustable Trim Clip
  • Mix and match widths for a striated visual
  • Install in the ceiling, on the wall, or create 90º angled or curved ceiling-to-wall transitions
  • Available for exterior applications, tested to meet wind uplift Classes 30, 60, and 90
  • Achieve high sound absorption for increased acoustical performance with microperforated planks
  • Fast and easy installation
  • Integrate with pre-engineered AXIOM Field Light Coves for Specialty Ceilings to achieve predictable lighting performance

Ceilings for Healing Environments

Addressing COVID-19 Concerns
View Solutions
Ceilings for Healing Environments
Acoustics

Acoustical options available.

  Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.
0.70
Fire
  Fire Performance Class A
Class A (FM)
Light Reflectance

Light reflectance average of 0.83 or greater. White only.
Up to 73%
Recycled Content

Recycled content range.
Up to 25%
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.
Standard
Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​.
Spray

May be sprayed following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines​.
Wipe

May be wiped following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines.
Durability
Soil Resistance

Excellent resistance to dirt and/or grease for lasting value and performance.
Impact Resistance

Surface impact based on the Striking Ball Impact Test, modified ASTM D1037 procedure.
Scratch Resistance

Excellent resistance to surface scratching, scuffing or chipping as per Hess Rake Test.
Washability

Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828.
Scrubbability

Withstands up to 150 scrub cycles using a scrubbability tester as per ATSM 02486.
Special Applications
  • Exterior
  • Library

Sustainability Profile

Recycled Content
Up To 25%
SUSTAINABLE PRODUCT SEARCH TOOL usGreenGenie_alt
Get Started

Project Gallery

Project Gallery

Sutter Van Ness
Project Gallery

Johns Hopkins Medicine Suburban Hospital
Project Gallery

Charleston Coliseum & Convention Center
Project Gallery

Watchguard Corporate Office
Project Gallery

Winter Park Health Foundation
Project Gallery

Pechanga Resort
Project Gallery

The Cypress of Charlotte Retirement Community Rec Center
Project Gallery

NASA Goddard Space Flight Center Goett Auditorium
Project Gallery

World Wide Technology Headquarters
Project Gallery

HNTB Office
Project Gallery

SPARK Holy Redeemer
Project Gallery

Colorado Tower

Videos

Installation

How to and Guides

  • Metalworks Linear Installation Overview

    Watch an in-depth dive into the installation techniques of our versatile MetalWorks Linear solution.

Accessories

5346
Pieces Per Carton
  • 6
6" Effects Wood Looks Trim
Length
  • 120 in
Width
  • 6 in
5494
5494
Pieces Per Carton
  • 16
Contrasts Filler Strip
Length
  • 96 in
Width
  • 1-1/4 in
5496
Pieces Per Carton
  • 50
8" Panel Splice
Length
  • 4 in
Width
  • 7-1/4 in
5574
Pieces Per Carton
  • 10
Flex Carrier Molding
5576
Pieces Per Carton
  • 50
Pressure Spring
Length
  • 2-1/2 in
Width
  • 1-3/16 in
5581
Pieces Per Carton
  • 50
4" Panel End Cap
Length
  • 1 in
Width
  • 4 in
5582
Pieces Per Carton
  • 50
8" Panel End Cap
Length
  • 1 in
Width
  • 8 in
5583
Pieces Per Carton
  • 50
12" Panel End Cap
Length
  • 1 in
Width
  • 12 in
7162
Pieces Per Carton
  • 50
MetalWorks Linear 6" Panel End Cap
Length
  • 1 in
Width
  • 6 in
7166
Pieces Per Carton
  • 50
MetalWorks Linear Carrier Splice for 6"
Length
  • 6 in
Width
  • 1 1/2 in
7177
7177
Pieces Per Carton
  • 10
MetalWorks Linear Main Beam Carrier Assembly
Length
  • 144 in
Width
  • 1-3/4 in
7237
7237
MetalWorks Linear Cut Plank Support Brkt
Length
  • 2-1/2 in
Width
  • 2-1/4 in
7239
7239
Adjustable Trim Clip
Length
  • 2-1/2 in
Width
  • 1-1/2 in
8138
Pieces Per Carton
  • 50
MetalWorks Linear - 2" End Cap
Width
  • 10 in
8139
Pieces Per Carton
  • 50
MetalWorks Linear - 10" End Cap
8159
Pieces Per Carton
  • 50
MetalWorks Linear - 2" Panel Splice
8161
Pieces Per Carton
  • 50
MetalWorks Linear - Pressure Spring
AX6VESTR
AX6VESTR
Component Type
  • Trim-Straight
Pieces Per Carton
  • 1
6in Axiom Vector Straight
Length
  • 120 in
Height
  • 6 in
Width
  • 3/4 in
XL7936G90
XL7936G90
Component Type
  • Cross Tee
Pieces Per Carton
  • 36
3ft Drywall Cross Tee G90
Length
  • 144 in
Height
  • 1-11/16 in
XL8945P
XL8945P
Component Type
  • Cross Tee
Pieces Per Carton
  • 36
4ft Drywall Cross Tee
Length
  • 48 in
Height
  • 1 1/2 in
