METALWORKS VECTOR and Vector Exterior

Durable, steel panels offer a 1/4" reveal and 100% downward accessibility.

Key Features & Performance

  • Now available in 17 EFFECTS wood-look finishes for interior and exterior applications
  • Exclusive VECTOR panel edge profile installs on new or existing 15/16" exposed tee suspension system resulting in a thin 1/4" reveal
  • CLEANASSURE family of products – includes disinfectable panels, suspension systems, and trim
  • Panels can be used to create continuous looks or clouds using AXIOM trim or EFFECTS Wood Looks trim
  • Standard perforations available to enhance acoustical performance and design aesthetics
  • Exterior system available, tested to meet wind uplift Classes 30, 60, and 90
  • Outstanding NRC with acoustical fleece or infill panel (0.65 – 0.90)
  • Installs with minimal plenum clearance
  • Plenum access per panel without the need of special tools
Material
Materials
Metal
Acoustics
Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.

0.10
Sound Blocking (CAC)

A measure for rating the performance of a ceiling system as a barrier to airborne sound transmission through a common plenum between adjacent closed spaces. A ceiling system with a CAC < 25 is considered low performance, whereas one with CAC of 35 or higher is high performance.

0.36
Fire
Fire Performance
Class A (FM)
Light
Light Reflectance

A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only.

Up to 77%
Anti-Microbial
Mold/Mildew Resistance

Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface.
Ceiling panels with BIOBLOCK Plus performance resist the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling panel surface.

Standard
Humidity
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.

Standard
Durability
Soil Resistance

Excellent resistance to dirt and/or grease for lasting value and performance.

Washability

Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828.

Scrubbability

Withstands up to 150 scrub cycles using a scrubbability tester as per ATSM 02486.

Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​

Spray

May be sprayed following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines​

Wipe

May be wiped following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines

Special Applications
Exterior
Library
FAST134 means standard specialty products in less than 4 weeks.
Complimentary ceiling design & pre-construction service.
Sustainability Profile
25%
Recycled Content
LEED  •  WELL  •  Living Building Challenge
Recycled/extended producer resp.
Recycled Content
Energy Management
Sourcing of Raw Materials
Construction Waste
Material Ingredient Reporting
Regional Materials
Location Dependent
Low emitting/materials
Design for Flexibility
Lighting Quality
EPD
Acoustics (With Infill Panels)
Biobased Materials

Configure an Item

Color shown may vary from actual product.
