SHORTSPAN Drywall Framing System

SHORTSPAN Drywall Framing System

The fastest and easiest way to frame flat drywall ceilings up to 17' wide.

Colors & Options

Unpainted
Custom color selected. Indicate color when specifying.
SHORTSPAN Drywall Framing System in Unpainted
Colors

Performance

ShortSpan Cross Tees

  • Easy, pre-engineered solution to support spans up to 8’-6’’ with no independent support
  • ScrewStop reverse hem prevents screw spin-off
  • Balanced profile stays flat during installation

Locking Angle Molding

  • Pre-engineered locking tabs punched 8" on center:
    • Eliminate measuring 16" or 24"O.C.
    • Locking tabs prevent lateral and upward movement
    • Eliminate screws, pop rivets, or crimpers needed to attach cross tees to molding
Fire
  Fire Resistance * FireGuard
Duty Ratings Heavy Duty
Intermediate Duty
Seismic Categories ** DEF
Corrosion Resistant Yes
* Not all systems for use in all UL designs
** Not all components can be used in all seismic categories
Face Dimensions 96 in
1-1/2 in
Profile Types Drywall/Stucco/Plaster
Exposed Tee
Materials Hot-dipped Galvanized Steel

Sustainability Profile

Recycled Content
Up To 61%
SUSTAINABLE PRODUCT SEARCH TOOL usGreenGenie_alt
Get Started
High Performance Sustainable Ceiling Systems usSustain_alt
Learn More
Living Building Challenge Compliant usDeclare_alt
Learn More

Videos

Installation

  • Fast & Easy Drywall Framing - ShortSpan 101

    Simplify and Speed Up Your Drywall Framing with the New ShortSpan®

  • ShortSpan Corridors

    Watch how fast we frame a 78-foot long by five-foot wide drywall corridor with ShortSpan tees.

  • ShortSpan Framing vs. Stud & Track Corridor Comparison

    Check out how Cliff breaks down the benefits of ShortSpan Drywall Framing System vs. Traditional Stud & Track for your next project.

Accessories

KAM10
KAM10
Component Type
  • Molding
Pieces Per Carton
  • 20
10ft Knurled Angle Molding 1-1/4" Face
Length
  • 120 in
Height
  • 1-1/4 in
KAM12
KAM12
Component Type
  • Molding
Pieces Per Carton
  • 20
12ft Knurled Angle Molding 1-1/4" Face
Length
  • 144 in
Height
  • 1-1/4 in
KAM12G90
KAM12G90
Component Type
  • Molding
Pieces Per Carton
  • 30
12ft Knurled Angle Molding 1-1/4" Face
Length
  • 144 in
Height
  • 1-1/4 in
KAM12HRC
KAM12HRC
Component Type
  • Molding
Pieces Per Carton
  • 20
12ft Knurled Angle Molding 1-1/4" Face
Length
  • 144 in
Height
  • 1-1/2 in
KAM1510
KAM1510
Component Type
  • Molding
Pieces Per Carton
  • 10
10ft Knurled Angle Molding 1-1/2" Face
Length
  • 120 in
Height
  • 1-1/2 in
KAM151020
KAM151020
Component Type
  • Molding
Pieces Per Carton
  • 10
10ft Knurled Angle Molding 1-1/2" Face
Length
  • 120 in
KAM151020EQ
KAM151020EQ
Component Type
  • Molding
Pieces Per Carton
  • 10
10ft Knurled Angle Molding 1-1/2" Face
Length
  • 120 in
KAM1512
KAM1512
Component Type
  • Molding
Pieces Per Carton
  • 20
12ft Knurled Angle Molding 1-1/2" Face
Length
  • 144 in
Height
  • 1-1/2 in
KAM151220E
KAM151220E
Component Type
  • Molding
Pieces Per Carton
  • 10
12ft Knurled Angle Molding 1-1/2" Face
Length
  • 144 in
KAM21020
KAM21020
Component Type
  • Molding
Pieces Per Carton
  • 12
10ft Knurled Angle Molding 2" Face
Length
  • 120 in
Height
  • 2 in
KAM21020EQ
KAM21020EQ
Component Type
  • Molding
Pieces Per Carton
  • 10
10ft Knurled Angle Molding 2" Face
Length
  • 120 in
Height
  • 2 in
KAM21025
KAM21025
Component Type
  • Molding
Pieces Per Carton
  • 12
10ft Knurled Angle Molding 2" Face
Length
  • 120 in
Height
  • 2 in
LAM12
LAM12
Component Type
  • Molding
Pieces Per Carton
  • 20
12ft Locking Angle Molding
Length
  • 144 in
Height
  • 1-1/4 in
LAM12G90
LAM12G90
Component Type
  • Molding
Pieces Per Carton
  • 30
12ft Locking Angle Molding
Length
  • 144 in
Height
  • 1-1/4 in
LAM12HRC
LAM12HRC
Component Type
  • Molding
Pieces Per Carton
  • 20
12ft Locking Angle Molding HRC
Length
  • 144 in
Height
  • 1-1/2 in
LAM151220E
Component Type
  • Molding
Pieces Per Carton
  • 10
12" Locking Angle Molding
Length
  • 144 in
Width
  • 1 1/2 in
LCM12
LCM12
Component Type
  • Molding
Pieces Per Carton
  • 10
12ft Locking Channel Molding
Length
  • 144 in
Height
  • 1-1/2 in
SC151220EQ
SC151220EQ
Component Type
  • Molding
Pieces Per Carton
  • 10
12' x 1.5" SimpleCurve Knurled Angle Molding – (.028" metal thickness)
Length
  • 148 in
Height
  • 1.5 in
Width
  • 1.5 in
SC151225
SC151225
Component Type
  • Molding
Pieces Per Carton
  • 10
12' x 1.5" SimpleCurve Knurled Angle Molding – (.018" metal thickness)
Length
  • 148 in
Height
  • 1.5 in
Width
  • 1.5 in
SC21220EQ
SC21220EQ
Component Type
  • Molding
Pieces Per Carton
  • 10
12' x 2" SimpleCurve Knurled Angle Molding – (.028" metal thickness)
Length
  • 148 in
Height
  • 2 in
Width
  • 2 in
SC21225
SC21225
Component Type
  • Molding
Pieces Per Carton
  • 10
12' x 2" SimpleCurve™ Knurled Angle Molding – (.018" metal thickness)
Length
  • 148 in
Height
  • 2 in
Width
  • 2 in
LWA12
LWA12
Component Type
  • Accessory
Pieces Per Carton
  • 26
12ft Capped Locking Wall Angle
Length
  • 144 in
Height
  • 7/8 in
LWAGU08
LWAGU08
Component Type
  • Accessory
Pieces Per Carton
  • 78
8in Locking Wall Angle Gusset
Length
  • 8 in
LWAGU12
LWAGU12
Component Type
  • Accessory
Pieces Per Carton
  • 78
12in Locking Wall Angle Gusset
Length
  • 12 in
LWAWT12
LWAWT12
Component Type
  • Accessory
Pieces Per Carton
  • 22
12ft Locking Wall Track
Length
  • 144 in
Height
  • 1-3/8 in
SB12
SB12
Component Type
  • Accessory
Pieces Per Carton
  • 12
Square Bulb Support Hanger
Used For
For suspension systems 12" knock out at 12" on-center.
Length
  • 96 in
Height
  • 2 in
Width
  • 1/4 in
SB12G90
SB12G90
Component Type
  • Accessory
Pieces Per Carton
  • 12
Square Bulb Support Hanger G90
Length
  • 96 in
Height
  • 2 in
Width
  • 1/4 in
SB12PG90
Component Type
  • Main Beam
Pieces Per Carton
  • 12
12' StrongBack PeakForm-G90
Length
  • 144 in
Height
  • 2 in
