WOODWORKS Open Cell
Select Color Swatch to View Lead Time
Color Not Part of FAST Program
- Edge: Vector 15/16"
- Dimensions: 24" x 48"
- Thickness: 3/4"
- Shape: Rectangle
- Slat Height: 2-1/4"
- Perforation: Four Square
-
Acoustics:
% Open Area: 82% - Fire Performance: Class C
- Face Profile: 15/16"
Product Details
Acoustics
Acoustical options available. |
|
---|---|
% Open Area
|
82% |
Fire | |
Fire Performance
|
Class C |
Sag/Humidity Resistance
Ceiling panels maintain humidity and sag resistance. |
Standard |
Disinfectability
|
|
Fog
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
|
Spray
May be sprayed following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
|
Wipe
May be wiped following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
Material
|
Wood |
---|---|
Texture
|
Open Cell |
Surface Finish
|
Ultra-violet clear semi-gloss coating |
Shape
|
Rectangle |
Weight
|
4.2 lbs/SF |
Sq Ft (Sq Ft / Piece)
|
8 |
Pieces / Carton
|
1 |
Installation Method
|
Grid (Suspended) |
Made In U.S.A. Of Domestic and Global Content
|
Yes |
Accessibility
Downward access for panels minimizes panel damage. |
Yes |
Contract Options
|
|
General Services Administration (GSA) Schedule
|
|
Cooperative Educational Services (CES)
|
|
California Multiple Award Schedules (CMAS)
|
Want to Improve the Acoustical Value of your design?
You've Added
Available Infill Panels
2820
Best
Calla 15/16" Sq Lay-in
0.85
35
1318
15/16" Square Lay-in 24 x 24 x 3/4"
0.75
30
5823
BioAcoustic Infill Panel (Black - Matte)
0.75
1713
Better
School Zone Fine Fissured
0.70
35
None
- Acoustical values achieved with infill panel. See data page for details.
Sustainability Profile
LEED • WELL • Living Building Challenge
Recyclable/Extended Producer Responsibility
|
FSC (for wood)
|
Energy Management
|
Recycled Content
|
Construction Waste
|
Sourcing of Raw Materials
|
Regional Materials
Location Dependent
|
Material Ingredient Reporting
|
Design for Flexibility
|
Low emitting/materials
|
EPD
|
Lighting Quality
|
Biobased Materials
|
Acoustics (With Infill Panels)
|
