ULTIMA Lay-In and Tegular

A smooth visual ceiling with TOTAL ACOUSTICS performance - sound absorption and blocking needed for today’s flexible spaces.

More…

Key Features & Performance

  • Reduce building HVAC energy costs and consumption up to 15%* with ULTIMA TEMPLOK ceiling panels (Items with suffix TEMP)
  • Made with sustainably produced carbon sequestering biochar (Items with suffix LEC)
  • Get total noise control and design flexibility with TOTAL ACOUSTICS ceiling panels: NRC + CAC = TOTAL ACOUSTICS performance
  • Enhance thermal comfort for occupants using advanced Phase Change Material (PCM) technology (Items with suffix TEMP)
  • DESIGNFLEX options include shapes and made-to-order sizes available to ship in 3 weeks
  • ULTIMA panels are part of the SUSTAIN portfolio, and meet the most stringent industry sustainability compliance standards today
  • CLEANASSURE family of products –includes disinfectable panels, suspension systems, and trim
  • Mold- and mildew-resistant surface
  • Smooth, clean, durable finish – Washable, Impact-resistant, Scratch-resistant, Soil-resistant
  • Ceiling-2-Ceiling Post-consumer Recycled Content options: items 1910HRC, 1913HRC. 71% Pre-consumer; 15% Post-consumer
  • USDA Certified Biobased Product – up to 100%
  • Available with AIRGUARD coating – actively removes formaldehyde from indoor air
  • Item 1910 available with CREATE! printed images and patterns
  • Non-directional visual reduces scrap and installation time
  • Compatible with the TECHZONE Ceiling Systems
  • 30-Year Limited System Warranty against visible sag (excludes items 1905 and 1929), mold, and mildew
  • 10-Year replacement panel available for items 1910, 1913

    * Measured cooling energy savings in lab test. Results may vary. See TEMPLOK Technical Guide for details.
Material
Materials
Mineral Fiber
Acoustics
Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.

Up to 0.75
Sound Blocking (CAC)

A measure for rating the performance of a ceiling system as a barrier to airborne sound transmission through a common plenum between adjacent closed spaces. A ceiling system with a CAC < 25 is considered low performance, whereas one with CAC of 35 or higher is high performance.

Up to 40
Articulation Class (AC)

Product has AC (Articulation Class) 170 or greater.

170
Fire
Fire Performance
Class A
Class A (25/450)
Class A (UL)
Fire Resistive
Fire Resistance *

FIRE GUARD/Fire Resistive products tested in specific UL floor/ceiling or roof/ceiling design assemblies.

FIREGUARD
Light
Light Reflectance

A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only.

88%
Anti-Microbial
Mold/Mildew Resistance

Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface.
Ceiling panels with BIOBLOCK Plus performance resist the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling panel surface.

BIOBLOCK
Humidity
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.

HUMIGUARD Plus
Standard
Durability
Soil Resistance

Excellent resistance to dirt and/or grease for lasting value and performance.

Impact Resistance

Surface impact based on the Striking Ball Impact Test, modified ASTM D1037 procedure.

Scratch Resistance

Excellent resistance to surface scratching, scuffing or chipping as per Hess Rake Test.

Washability

Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828.

Scrubbability

Withstands up to 150 scrub cycles using a scrubbability tester as per ATSM 02486.

Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​

Sustainability
USDA certified biobased content

This product is part of the USDA BioPreferred Program and it's biobased content has been independently laboratory tested and third-party certified.

95%
Special Applications
Library
Music / Language Room
* Not all systems for use in all UL designs

New Energy Saving Ceilings

Save energy and contribute to sustainable, healthy and resilient spaces. Learn more about TEMPLOK Ceiling benefits including energy saving performance. Request a complimentary Space Audit from our expert team.

The ideal combination of sound absorption & sound blocking.
Complimentary ceiling design & pre-construction service.
Sustainability Profile
Up to
87%
Recycled Content
Sustainable Product Search Tool
Recyclable via the Armstrong Ceilings Recycling Program
LEED  •  WELL  •  Living Building Challenge
Recyclable/Extended Producer Responsibility
Recycled Content
Energy Management
Sourcing of Raw Materials
Construction Waste
Material Ingredient Reporting
Regional Materials
Location Dependent
Low emitting/materials
Design for Flexibility
Lighting Quality
EPD
Acoustics
Biobased Materials
High Performance Sustainable Ceiling Systems
