LYRA Plant Based (PB) High CAC
- Edge: Square Lay-In 15/16"
- Dimensions: 24" x 48"
- Thickness: 1-3/4"
- Shape: Rectangle
-
Acoustics:
NRC: 0.95CAC: 44AC: 200 - Fire Performance: Class A
- Light Reflectance: 88%
- Face Profile: 15/16"
Product Details
Acoustics
Acoustical options available. |
|
---|---|
Sound Absorption (NRC)
A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance. |
0.95 |
Sound Blocking (CAC)
A measure for rating the performance of a ceiling system as a barrier to airborne sound transmission through a common plenum between adjacent closed spaces. A ceiling system with a CAC < 25 is considered low performance, whereas one with CAC of 35 or higher is high performance. |
44 |
Articulation Class (AC)
Product has AC (Articulation Class) 170 or greater. |
200 |
Fire | |
Fire Performance
|
Class A |
Light Reflectance
A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only. |
88% |
Sag/Humidity Resistance
Ceiling panels maintain humidity and sag resistance. |
HUMIGUARD Plus |
Insulation Value
|
R Factor-BTU: 5.72 BTU R Factor-Watts: 1.00 m2 K/W |
Mold/Mildew Resistance
Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface. |
BIOBLOCK |
Disinfectability
|
|
Fog
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
|
Durability
|
|
Soil Resistance
Excellent resistance to dirt and/or grease for lasting value and performance. |
|
Scratch Resistance
Excellent resistance to surface scratching, scuffing or chipping as per Hess Rake Test. |
|
Washability
Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828. |
Material
|
Composite |
---|---|
Texture
|
Smooth |
Surface Finish
|
Acoustically transparent membrane with factory applied latex paint |
Shape
|
Rectangle |
Weight
|
1.77 lbs/SF |
Sq Ft (Sq Ft / Carton)
|
16 |
Pieces / Carton
|
2 |
ASTM Classification
|
Type: B, Form: B2, Pattern: G |
Installation Method
|
Grid (Suspended) |
Made In U.S.A. Of Domestic and Global Content
|
Yes |
Accessibility
Downward access for panels minimizes panel damage. |
Yes |
Contract Options
|
|
General Services Administration (GSA) Schedule
|
|
Allied States Cooperative
|
|
Cooperative Educational Services (CES)
|
|
California Multiple Award Schedules (CMAS)
|
