CASTWORKS METAPHORS Ceiling Panels
Select Color Swatch to View Lead Time
Color Not Part of FAST Program
- Edge: Square Tegular 9/16"
- Dimensions: 24" x 24"
- Pattern: Tectonic with Flat Area
- Fire Performance: Class A
- Light Reflectance: 79%
- Face Profile: 9/16"
Product Details
Fire | |
---|---|
Fire Performance
|
Class A |
Light Reflectance
A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only. |
79% |
Disinfectability
|
|
Fog
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
|
Spray
May be sprayed following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
Material
|
Glass Fiber Reinforced Gypsum (GRG) |
---|---|
Texture
|
Smooth |
Surface Finish
|
Factory applied latex paint |
Weight
|
2.825 lbs/SF |
Sq Ft (Sq Ft / Carton)
|
12 |
Pieces / Carton
|
3 |
Installation Method
|
Grid (Suspended) |
Accessibility
Downward access for panels minimizes panel damage. |
Yes |
Contract Options
|
|
General Services Administration (GSA) Schedule
|
|
Cooperative Educational Services (CES)
|
|
California Multiple Award Schedules (CMAS)
|
Sustainability Profile
LEED • WELL • Living Building Challenge
Recyclable/Extended Producer Responsibility
|
Recycled Content
|
Energy Management
|
Sourcing of Raw Materials
|
Construction Waste
|
Material Ingredient Reporting
|
Regional Materials
Location Dependent
|
Low emitting/materials
|
Design for Flexibility
|
Lighting Quality
|
EPD
|
Acoustics
|
Biobased Materials
|
