CALLA TEMPLOK

Smooth texture mineral fiber ceiling combines exceptional acoustical performance, energy savings and enhanced thermal comfort using advanced Phase Change Material (PCM) technology.

Key Features & Performance

Total Acoustics
Made In U.S.A. Of Domestic and Global Content
Buy America, Build America Act
Energy Saving Ceilings
  • Reduce building HVAC energy costs and consumption up to 15%* with CALLA TEMPLOK ceiling panels
  • Enhance thermal comfort for occupants using advanced Phase Change Material (PCM) technology
  • Get total noise control and design flexibility with TOTAL ACOUSTICS ceiling panels: NRC + CAC = TOTAL ACOUSTICS performance
  • Excellent combination of acoustical performance; NRC 0.85, and CAC 39
  • CLEANASSURE family of products – includes disinfectable panels, suspension systems, and trim
  • Mold- and mildew-resistant surface
  • USDA Certified Biobased Product – 91%
  • Washable, Scratch-resistant, Soil-resistant
  • Compatible with the TECHZONE Ceiling System
  • Product can be recycled through the Armstrong Ceilings Recycling Program
  • 30-Year Limited System Warranty against visible sag, mold, and mildew

    * Measured cooling energy savings in lab test. Results may vary. See TEMPLOK Technical Guide for details.
Material
Materials
Mineral Fiber
Acoustics
Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.

0.85
Sound Blocking (CAC)

A measure for rating the performance of a ceiling system as a barrier to airborne sound transmission through a common plenum between adjacent closed spaces. A ceiling system with a CAC < 25 is considered low performance, whereas one with CAC of 35 or higher is high performance.

39
Fire
Fire Performance
Class A (25/450)
Light
Light Reflectance

A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only.

85%
Anti-Microbial
Mold/Mildew Resistance

Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface.
Ceiling panels with BIOBLOCK Plus performance resist the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling panel surface.

BIOBLOCK
Humidity
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.

HUMIGUARD Plus
Durability
Soil Resistance

Excellent resistance to dirt and/or grease for lasting value and performance.

Impact Resistance

Surface impact based on the Striking Ball Impact Test, modified ASTM D1037 procedure.

Scratch Resistance

Excellent resistance to surface scratching, scuffing or chipping as per Hess Rake Test.

Washability

Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828.

Scrubbability

Withstands up to 150 scrub cycles using a scrubbability tester as per ATSM 02486.

Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​

Special Applications
Library
Music / Language Room
Made In U.S.A. Of Domestic and Global Content
Yes

New Energy Saving Ceilings

Save energy and contribute to sustainable, healthy and resilient spaces. Learn more about TEMPLOK Ceiling benefits including energy saving performance. Request a complimentary Space Audit from our expert team.

The ideal combination of sound absorption & sound blocking.
Complimentary ceiling design & pre-construction service.
Sustainability Profile
Sustainable Product Search Tool
Recyclable via the Armstrong Ceilings Recycling Program
LEED  •  WELL  •  Living Building Challenge
Recyclable/Extended Producer Responsibility
Recycled Content
Energy Management
Sourcing of Raw Materials
Construction Waste
Material Ingredient Reporting
Regional Materials
Location Dependent
Low emitting/materials
Design for Flexibility
Lighting Quality
EPD
Acoustics
Biobased Materials

Configure an Item

Installation Recommendation

TEMPLOK panels cannot be cut. Use related CALLA Tegular or Lay-In item for borders and cutting needs.
