Product Details
|
Acoustics
Acoustical options available. |
|
|---|---|
|
Sound Absorption (NRC)
A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance. |
1.00 |
|
Articulation Class (AC)
Product has AC (Articulation Class) 170 or greater. |
190 |
| Fire | |
|
Fire Performance
|
Class A (UL) |
|
Light Reflectance
A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only. |
88% |
|
Sag/Humidity Resistance
Ceiling panels maintain humidity and sag resistance. |
HUMIGUARD Plus |
|
Insulation Value
|
R Factor-BTU: 6.00 BTU R Factor-Watts: 1.05 m2 K/W |
|
Mold/Mildew Resistance
Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface. |
Inherent |
|
Disinfectability
|
|
|
Fog
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
|
|
Durability
|
|
|
Soil Resistance
Excellent resistance to dirt and/or grease for lasting value and performance. |
|
|
Impact Resistance
Surface impact based on the Striking Ball Impact Test, modified ASTM D1037 procedure. |
|
|
Scratch Resistance
Excellent resistance to surface scratching, scuffing or chipping as per Hess Rake Test. |
|
|
Washability
Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828. |
|
|
Special Applications
|
|
|
Material
|
Fiberglass |
|---|---|
|
Texture
|
Fine |
|
Surface Finish
|
Factory-applied latex paint on DuraBrite acoustically transparent membrane |
|
Shape
|
Rectangle |
|
Weight
|
0.61 lbs/SF |
|
Sq Ft (Sq Ft / Carton)
|
64 |
|
Pieces / Carton
|
8 |
|
ASTM Classification
|
Type: B, Form: B2, Pattern: E |
|
Installation Method
|
Grid (Suspended) |
|
Made In U.S.A. Of Domestic and Global Content
|
Yes |
|
Contract Options
|
|
| General Services Administration (GSA) Schedule | |
| Allied States Cooperative | |
| Cooperative Educational Services (CES) | |
| California Multiple Award Schedules (CMAS) | |
