METALWORKS Torsion Spring

A monolithic visual with a unique hide-the-grid installation and 100% swing-down accessibility.

Key Features & Performance

  • Four new SEQUELS pre-coat, wood-look finishes are part of the FAST134 program, including downlight panels
  • Seventeen standard EFFECTS wood-look finishes offer on-trend design options in bold, subtle, and classic woodgrain looks
  • Natural Reflections laminate finishes provide superior wood-look visual with printed vinyl bonded to aluminum, now Class A and Canadian fire tested; visuals other than the ones shown are also available
  • Precise factory-cut downlight panels are fit-and-finish certified to integrate with USAI® Lighting BeveLED® 2.2 and BeveLED® Mini trimless downlights
  • Sustainable Beyond Standard: Select standard and custom panels are part of the SUSTAIN portfolio, and meet the most stringent industry sustainability compliance standards today
  • CLEANASSURE family of products – includes disinfectable panels, suspension systems, and trim
  • Select products included in the FAST134 program – ready to ship in 4 weeks or less
  • Transform your images onto custom perforated METALWORKS CREATE! ceiling panels for a unique aesthetic plus acoustical performance
  • Interior panels feature swing-down accessibility
  • Exterior options available in 24 x 24 x 1-1/2" and 24 x 48 x 1-1/2" standard panel sizes
  • NRC values up to 0.90 with fiberglass infill panels (select perforation patterns)
  • Washable and impact-, scratch-, and soil-resistant
Acoustics
Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.

Up to 0.75
Fire
Fire Performance
Class A
Light
Light Reflectance

A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only.

Up to 75%
Anti-Microbial
Mold/Mildew Resistance

Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface.
Ceiling panels with BIOBLOCK Plus performance resist the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling panel surface.

Standard
Humidity
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.

Standard
Durability
Soil Resistance

Excellent resistance to dirt and/or grease for lasting value and performance.

Impact Resistance

Surface impact based on the Striking Ball Impact Test, modified ASTM D1037 procedure.

Washability

Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828.

Scrubbability

Withstands up to 150 scrub cycles using a scrubbability tester as per ATSM 02486.

Disinfectability
Spray

May be sprayed following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines​

Wipe

May be wiped following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines

Special Applications
Exterior
Library
FAST134 means standard specialty products in less than 4 weeks.
Complimentary ceiling design & pre-construction service.
Sustainability Profile
16%
Recycled Content
LEED  •  WELL  •  Living Building Challenge
Recycled/extended producer resp. Recycled Content
Energy Management Sourcing of Raw Materials
Construction Waste Material Ingredient Reporting
Regional Materials
Location Dependent
Low emitting/materials
Design for Flexibility Lighting Quality
EPD Acoustics
Biobased Materials
High Performance Sustainable Ceiling Systems
Learn More
Living Building Challenge Compliant
Learn More
