SCHOOL ZONE Fine Fissured AirAssure: 2806

  • SCHOOL ZONE Fine Fissured AirAssure
  • SCHOOL ZONE Fine Fissured AirAssure
SCHOOL ZONE Fine Fissured AirAssure
SCHOOL ZONE Fine Fissured AirAssure
Edge Dimensions Acoustics Lead Time Lead Time Lead Time Lead Time Lead Time
Square Lay-In 15/16
Square Lay-In 15/16 in
24 in x 24 in
24 in x 24 in x 3/4 in
0.70 NRC
42 CAC
170 AC
FAST1
FAST1
1 Week or Less Order-to-Ship
FAST3
FAST3
3 Weeks or Less Order-to-Ship
FAST4
FAST4
4 Weeks or Less Order-to-Ship
fast
Select Color Swatch to View Lead Time
fast
Color Not Part of FAST Program
NOTE: Shape drawings are not to scale.
See Technical Details
Create Specification

Performance

  • Factory-gasketed edges reduce air leakage through the ceiling plane in a space up to 4X compared to panels without AirAssure performance
  • AirAssure ceilings enable easy conversion to negative or positive pressure-controlled spaces (without hold-down clips)
  • Get total noise control and floor plan versatility with TOTAL ACOUSTICS ceiling panels: NRC + CAC = TOTAL ACOUSTICS Performance
  • Excellent sound blocking: SCHOOL ZONE Fine Fissured AirAssure panels with TOTAL ACOUSTICS performance provide up to 45 CAC
  • CLEANASSURE family of products – includes disinfectable panels, suspension systems, and trim
  • SCHOOL ZONE Fine Fissured AirAssure panels are part of the Sustain® portfolio, and meet the most stringent industry sustainability compliance standards today
  • Anti-Mold/Mildew - Ceiling tiles with BioBlock performance resist the growth of mold and mildew on the ceiling tile surface
  • Exceeds ANSI S12.60 Classroom Acoustic requirements
  • Meets USDA/FSIS guidelines
  • Panels: 30-Year Limited System Warranty against visible sag, mold, and mildew and bacterial growth
Acoustics

Acoustical options available.

Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.
0.70
Sound Blocking (CAC)

A measure for rating the performance of a ceiling system as a barrier to airborne sound transmission through a common plenum between adjacent closed spaces. A ceiling system with a CAC < 25 is considered low performance, whereas one with CAC of 35 or higher is high performance.
42
Articulation Class (AC)

Product has AC (Articulation Class) 170 or greater.
170
Fire
  Fire Performance Class A
Light Reflectance

Light reflectance average of 0.83 or greater. White only.
85%
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.
HumiGuard Plus
Insulation Value R Factor-BTU: 1.50 BTU
BioBlock

Ceiling tiles with BioBlock performance resist the growth of mold and mildew on the ceiling tile surface.
Yes
Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​.
Spray

May be sprayed following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines​.
Material Mineral Fiber
Texture Fine
Surface Finish Factory applied latex paint
Shape Rectangle
Weight 1.27 PF2
Sq Ft (Sq Ft / Carton) 48
Pieces / Carton 12
ASTM Classification Type: III, Form: 2, Pattern: C E
Installation Method Grid (Suspended)

Accessibility

Accessibility

Downward access for panels minimizes panel damage.
Yes

Sustainability Profile

SUSTAINABLE PRODUCT SEARCH TOOL usGreenGenie_alt
Get Started
High Performance Sustainable Ceiling Systems usSustain_alt
Learn More
Living Building Challenge Compliant usDeclare_alt
Learn More

Videos

Installation

How to and Guides

Compatible Grid & Trim

PRELUDE XL 15/16" Exposed Tee
PRELUDE XL 15/16" Exposed Tee

This hot-dipped galvanized steel 15/16" suspension system offers high recycled content for improved LEED credits.
PRELUDE Plus XL Stainless Steel 15/16" Exposed Tee
PRELUDE Plus XL Stainless Steel 15/16" Exposed Tee

These steel 15/16" suspension systems are designed for severe environmental performance.
PRELUDE Plus XL Aluminum 15/16" Exposed Tee
PRELUDE Plus XL Aluminum 15/16" Exposed Tee

These aluminum 15/16" suspension systems are designed for severe environmental performance.
