WOODWORKS Shapes for DESIGNFlex: 8281W1

  • WOODWORKS Shapes for DESIGNFlex
  • WOODWORKS Shapes for DESIGNFlex
WOODWORKS Shapes for DESIGNFlex
WOODWORKS Shapes for DESIGNFlex
FAST Program: click color swatches to view associated lead times.
Edge Dimensions Perforation Lead Time Lead Time Lead Time Lead Time Lead Time
Square Tegular 9/16
Square Tegular 9/16 in
Trapezoid - Wood Grain
24 in x 48 in x 3/4 in
 W1 - Unperforated
FAST1
FAST1
1 Week or Less Order-to-Ship
FAST3
FAST3
3 Weeks or Less Order-to-Ship
FAST4
FAST4
4 Weeks or Less Order-to-Ship
fast
Select Color Swatch to View Lead Time
fast
Color Not Part of FAST Program
NOTE: Shape drawings are not to scale.
See Technical Details

Performance

  • Get a custom, one-of-a-kind look with standard WOODWORKS Shapes without custom lead times
  • Add ULTIMA Shapes Lay-in acoustic infill panels to get total noise control and design versatility with TOTAL ACOUSTICS ceiling panels: NRC + CAC = TOTAL ACOUSTICS PERFORMANCE
  • Mix and match – Shapes also available with CALLA, LYRA, ULTIMA, OPTIMA, and METALWORKS panels
  • Create a cohesive look with:
    • TECHZONE systems
    • Shaped lighting and diffusers
    • JLC-Tech T-BAR FLEX™ LED
  • All clips and safety accessories included and shipped with panels
  • NOTE: The grain direction runs parallel to the main beam in the suspension system
Acoustics

Acoustical options available.

  % Open Area 0%
Fire
  Fire Performance Class A
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.
Standard
Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​.
Spray

May be sprayed following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines​.
Wipe

May be wiped following CDC recommendations using EPA disinfectant​ cleaners per Armstrong Cleaning & Disinfecting Guidelines.
Material Fire-retardant Particle Board
Surface Finish Varies depending on color
Shape Trapezoid - Wood Grain
Weight 2.75 PF2
Sq Ft (Sq Ft / Carton) 6
Pieces / Carton 1
ASTM Classification Type: XX, Pattern: Z
Installation Method Grid (Suspended)

Accessibility

Accessibility

Downward access for panels minimizes panel damage.
Yes

Sustainability Profile

SUSTAINABLE PRODUCT SEARCH TOOL usGreenGenie_alt
Get Started
USDA BIOPREFERRED® PROGRAM
LEARN MORE

Installation

How to and Guides

Compatible Grid & Trim

SUPRAFINE XM 9/16" Exposed Tee System for Shapes
SUPRAFINE XM 9/16" Exposed Tee System for Shapes

For use with our DESIGNFlex portfolio of ceiling systems.

Accessories

BERC2
BERC2
Component Type
  • Clip
Pieces Per Carton
  • 200
2" Beam End Retaining Clip (steel)
Used For
Joins main beam or cross tee to wall molding with no visible pop rivets.(steel)
PAC
PAC
Component Type
  • Clip
Pieces Per Carton
  • 50
Perimeter Angle Clip
PCC
PCC
Component Type
  • Clip
Pieces Per Carton
  • 10
Axiom Perimeter Corner Clip
75AB60D
75AB60D
Component Type
  • Angle Bracket
Pieces Per Carton
  • 10
Suprafine 60° Double Angle Bracket
Length
  • 2.43 in
Height
  • .980 in
Width
  • 2.47 in
75AB60L
75AB60L
Component Type
  • Angle Bracket
Pieces Per Carton
  • 10
Suprafine 60° Left Angle Bracket
Length
  • 2.81 in
Height
  • .980 in
Width
  • 0.562 in
75AB60R
75AB60R
Component Type
  • Angle Bracket
Pieces Per Carton
  • 10
Suprafine 60° Right Angle Bracket
Length
  • 2.81 in
Height
  • .980 in
Width
  • 0.562 in
XM7524
XM7524
Component Type
  • Perimeter Cross Tee
Pieces Per Carton
  • 60
Suprafine Perimeter Cross Tee - 24" Main Beam Spacing
Length
  • 34 in
Height
  • 1-11/16 in
Width
  • 9/16 in
XM756024
XM756024
Component Type
  • Cross Tee
Pieces Per Carton
  • 60
Suprafine 60° Cross Tee - 24" Main Beam Spacing
Length
  • 22.677 in
Height
  • 1-11/16 in
Width
  • .563 in
