Drywall Grid Accessories

Drywall Grid Accessories

Accessories to install the Armstrong Drywall Grid System.

Performance

Fire
  Fire Resistance * FireGuard
Seismic Categories ** DEF
* Not all systems for use in all UL designs
** Not all components can be used in all seismic categories
Profile Types Drywall/Stucco/Plaster
Exposed Tee

Sustainability Profile

SUSTAINABLE PRODUCT SEARCH TOOL usGreenGenie_alt
Get Started

Project Gallery

Project Gallery

Morehead State University Student Center

Videos

Installation

  • Single Tee Adapter Clip - STAC

    STAC Clip or Single Tee Adapter Clip allows you to create off-module or staggered grid installation for both non-seismic areas, seismic C, and seismic DEF. Learn more in this short video.

  • DLCC Direct Load Ceiling Clip

    The DLCC clip is a direct load clip that allows you to tie a hanger wire to a structure, but then hang another ceiling below making your upper ceiling a sub ceiling. Learn more about this clip in this short video.

  • Acoustical Wall Angle Corner Covers

    Use our corner covers to to make more visually appealing wall angle joints and complete your cuts in less time with architect and GC approvals. Learn how in this short video.

  • RC2 Radius Clip

    Here we have the RC2 clip that allows you to work with acoustical or drywall grid system when working with radius. Learn how to install this with convex and concave installations.

  • Knurled Angle Molding | KAM

    Learn why KAM (knurled angle molding) is safer and easier to handle than standard SHINY 90.

  • Impact Isolation Clip for Drywall Grid Systems

    "Control sound between drywall ceiling spaces and eliminate costly isolation hangers. The impact isolation clip drywall main runners have a sound dampening isolator built-in - just hang your drywall main runners and cross tees as you would any standard installation. The 4’ on-center built-in isolation clips exceed IBC requirements with an amazing IIC rating of 66 and STC rating of 57."

  • Axiom Pockets for Lutron Shades

    The Lutron Compatible Shade Pocket is an integrated pocket and shading solution for building perimeter systems, thanks to a collaboration between Armstrong and Lutron. This pre-engineered solution provides superior aesthetics, performance, and the mo

Accessories

GSC12
GSC12
Component Type
  • Accessory
Pieces Per Carton
  • 100
Adjustable Grid Spacer - 4-8" Main Beam Spacing
Used For
to space two parallel main beams for light fixtures, air diffusers, etc.; allows for 1/4" adjustments with three different clips.
Length
  • 12 in
GSC16
GSC16
Component Type
  • Accessory
Pieces Per Carton
  • 100
Adjustable Grid Spacer - 8-16" Main Beam Spacing
Used For
to space two parallel main beams for light fixtures, air diffusers, etc.; allows for 1/4" adjustments with three different clips.
Length
  • 16 in
GSC9
GSC9
Component Type
  • Accessory
Pieces Per Carton
  • 100
Adjustable Grid Spacer - 1-4" Main Beam Spacing
Used For
Used to space two parallel main beams for light fixtures, air diffusers, etc.; allows for 1/4" adjustments with three different clips.
Length
  • 9 in
TT10
TT10
Component Type
  • Accessory
Pieces Per Carton
  • 30
10ft Partition Top Trim
Used For
to finish off the top of a drywall partition for a continuous drywall/acoustic ceiling interface
Length
  • 120 in
ALBERC2
ALBERC2
Component Type
  • Clip
Pieces Per Carton
  • 200
Aluminum Beam End Retaining Clip
Used For
Joins main beam or cross tee to wall molding with no visible pop rivets.
DDC
DDC
Component Type
  • Clip
Pieces Per Carton
  • 250
Double Drywall Clip
Used For
to hang suspension system below existing 1-1/2" grid face, transferring weight directly to hanger wire; may be used to preserve the fire rating of an existing ceiling and to support heavy accessories; allows for double layer of 5/8" gypsum board
DLCC
DLCC
Component Type
  • Clip
Pieces Per Carton
  • 250
Direct Load Ceiling Clip
Used For
To hang suspension system below existing 15/16" grid face, transferring weight directly to hanger wire; may be used to preserve the fire rating of an existing ceiling and to support heavy accessories.
DW30CG
DW30CG
Component Type
  • Clip
Pieces Per Carton
  • 250
30 Degree Drywall Angle Clip
Used For
to create positive and secure angles for drywall and ceiling installations on either main beams or cross tees; attachment to be made with 7/16" pan head screw
DW45CG
DW45CG
Component Type
  • Clip
Pieces Per Carton
  • 250
45 Degree Drywall Angle Clip
Used For
to create positive and secure angles for drywall and ceiling installations on either main beams or cross tees; attachment to be made with 7/16" pan head screw
DW50LT
DW50LT
Component Type
  • Clip
Pieces Per Carton
  • 125
Transition Clip for 1/2" Drywall
Used For
Facilitates transition from drywall to acoustical ceiling; one-sided hold down clip; eliminates need for drywall bead. Locking tabs provide secure location for DGS tees
DW58
DW58
Component Type
  • Clip
Pieces Per Carton
  • 125
Transition Clip for 5/8in Drywall
DW58LT
DW58LT
Component Type
  • Clip
Pieces Per Carton
  • 125
Transition Clip for 5/8" Drywall
Used For
Facilitates transition from drywall to acoustical ceiling; one-sided hold down clip; eliminates need for drywall bead. Locking tabs provide secure location for DGS tees
DW90C
DW90C
Component Type
  • Clip
Pieces Per Carton
  • 250
90 Degree Drywall Angle Clip
Used For
Used to create positive and secure angles for drywall and ceiling installations on either main beams or cross tees; attachment to be made with 7/16" pan head screw
DWC
DWC
Component Type
  • Clip
Pieces Per Carton
  • 250
Drywall Clip
Used For
Allows for a “second” ceiling to be installed below a drywall ceiling; attach through installed drywall to supporting structure; DWC approved for use in UL Designs P237, P239, P240, and P241.
GC3W
GC3W
Component Type
  • Clip
Pieces Per Carton
  • 250
3 Way Grip Clip
Used For
Joins main beams to cross tee via locking barbs without pop rivets or screws.
IIC
IIC
Component Type
  • Clip
Pieces Per Carton
  • 36
IIC Sound Isolation Clip for HD8906IIC Main Beam
Used For
For use with HD8906IIC drywall grid main beam. Provides up to 8 points of IIC improvement to ensure your project meets IBC requirements.
MBAC
MBAC
Component Type
  • Clip
Pieces Per Carton
  • 70
Main Beam Adapter Clip
Used For
Attaches to web of suspension system section; provides larger surface for screw attachments; used as a hold down clip for thin material (metal or plastic lay-in panels); fastens drywall track to underside of exposed suspension system with lay-in panels, leaving suspension system face free of screw holes
RC1
RC1
Component Type
  • Clip
Pieces Per Carton
  • 200
Radius Clip
Used For
as a main beam splice or partition top trim splice
RC2
RC2
Component Type
  • Clip
Pieces Per Carton
  • 205
Radius Clip
Used For
drywall applications which form curved installations; attaches to the cavity side of web of the main beam with four 7/16" pan head screws. Install at all knockout locations.
MBACAG
Pieces Per Carton
  • 70
Main Beam Adapter Clip
