Accessories and Moldings - Seismic

Accessories and Moldings - Seismic

Help meet Seismic installation requirements with angle moldings, shadow moldings, channel moldings, and other wall moldings - which are an important detail in the design and installation of each ceiling system.

Performance

Profile Types Bolt-Slot
Dimensional Tee
Drywall/Stucco/Plaster
Exposed Tee

Sustainability Profile

SUSTAINABLE PRODUCT SEARCH TOOL usGreenGenie_alt
Get Started

Videos

Installation

  • [Discontinous Ceilings] SS Shapes Individual Installation US

    [Discontinous Ceilings] SS Shapes Individual Installation US

  • BERC2 – Beam End Retaining Clip

    The BERC2 clip or beam end retaining clip eliminates two-inch wall angle in Seismic D, E, and F, and in C installation it allows for easier installation. Learn more in this short video.

Accessories

AXSJ
AXSJ
Component Type
  • Transition
Pieces Per Carton
  • 1
Axiom Slip Joint
Used For
to join two acoustical ceiling systems on seismic D, E, F installations. Can also be used to join two different ceiling systems. Hanger wire holes every 6”, beginning 3" from each end.
Length
  • 120 in
Width
  • 2-1/4 in
5594
Component Type
  • Accessory
Compression Strut
7425
7425
Component Type
  • Accessory
Pieces Per Carton
  • 100
Stabilizer Bar
Used For
maintaining uniform spacing of suspension system components (main beams and cross tees).
Length
  • 24 in
7445
7445
Component Type
  • Accessory
Pieces Per Carton
  • 100
Stabilizer Bar
Used For
maintaining uniform spacing of suspension system components (main beams and cross tees).
Length
  • 48 in
ES4
ES4
Component Type
  • Accessory
Pieces Per Carton
  • 100
Expansion Sleeves (for 15/16")
Length
  • 4 in
Width
  • 15/16 in
ES49
ES49
Component Type
  • Accessory
Pieces Per Carton
  • 100
Expansion Sleeves (for 9/16")
Length
  • 4 in
Width
  • 9/16 in
ES76004
ES76004
Component Type
  • Accessory
Pieces Per Carton
  • 200
Expansion Sleeves (for 1/4")
Length
  • 4 in
ES76008
ES76008
Component Type
  • Accessory
Pieces Per Carton
  • 200
Expansion Sleeves (for 1/8")
Length
  • 4 in
GA7327
GA7327
Component Type
  • Accessory
Pieces Per Carton
  • 60
Grid Adapter
Length
  • 27 in
Height
  • 1-1/2 in
GCWA
GCWA
Component Type
  • Accessory
Pieces Per Carton
  • 250
Grip clip wall attachment
Used For
Joins main beam or cross tee to wall molding via locking barbs without pop rivets or screws.
SB12
SB12
Component Type
  • Accessory
Pieces Per Carton
  • 12
Square Bulb Support Hanger
Used For
For suspension systems 12" knock out at 12" on-center.
Length
  • 96 in
Height
  • 2 in
Width
  • 1/4 in
TZYK
TZYK
Component Type
  • Accessory
Pieces Per Carton
  • 100
TechZone Yoke
Used For
Create a sleek ceiling design with uninterrupted ribbons of light
414
414
Component Type
  • Clip
Pieces Per Carton
  • 100
Retention Clip
7870
7870
Component Type
  • Clip
Pieces Per Carton
  • 1000
Spring Border Clip
Used For
installations with the panel resting on the wall molding
ALBERC2
ALBERC2
Component Type
  • Clip
Pieces Per Carton
  • 200
Aluminum Beam End Retaining Clip
Used For
Joins main beam or cross tee to wall molding with no visible pop rivets.
BACG90A
BACG90A
Component Type
  • Clip
Pieces Per Carton
  • 200
Wind Uplift Clip
BERC
BERC
Component Type
  • Clip
Pieces Per Carton
  • 200
Beam End Retaining Clip
Used For
Joins main beam or cross tee to wall molding with no visible pop rivets.
BERC2
BERC2
Component Type
  • Clip
Pieces Per Carton
  • 200
2" Beam End Retaining Clip (steel)
Used For
Joins main beam or cross tee to wall molding with no visible pop rivets.(steel)
FXSPTHDC
Component Type
  • Clip
Pieces Per Carton
  • 10
Effects Hold Down Clip
GC3W
GC3W
Component Type
  • Clip
Pieces Per Carton
  • 250
3 Way Grip Clip
Used For
Joins main beams to cross tee via locking barbs without pop rivets or screws.
QSUTC
QSUTC
Component Type
  • Clip
Pieces Per Carton
  • 150
Rigid Attachment Clip
Used For
Saves time in tight plenum areas and is adjustable to uneven surfaces.
Width
  • 1-1/2 in
SJCG
SJCG
Component Type
  • Clip
Pieces Per Carton
  • 200
Seismic Joint Clip CT (PeakForm)
SJCSI
SJCSI
Component Type
  • Clip
Pieces Per Carton
  • 200
Seismic Joint Clip CT (square bulbs)
Used For
Offers a tested seismic solution for separation joints in Seismic Category D, E, and F installations.
SJMR15
SJMR15
Component Type
  • Clip
Pieces Per Carton
  • 100
Seismic Joint Clip - Main Beam (for 15/16")
Used For
Allows the ceiling to be divided at a splice on the main beam to accommodate the IBC mandate for ceiling areas greater than 2500 SF to have seismic separation joints. ES4 expansion sleeve is used to cover 3/4" gap
SJMR9
SJMR9
Component Type
  • Clip
Pieces Per Carton
  • 100
Seismic Joint Clip - Main Beam (for 9/16")
Used For
Allows the ceiling to be divided at a splice on the main beam to accommodate the IBC mandate for ceiling areas greater than 2500 SF to have seismic separation joints. ES4 expansion sleeve is used to cover 3/4" gap
STAC
STAC
Component Type
  • Clip
Pieces Per Carton
  • 120
Single Tee Adapter Clip
Used For
to create code compliant non-seismic and seismic C and D, E, F off-module single tee to main beam connection.
TZBC
TZBC
Component Type
  • Clip
Pieces Per Carton
  • 100
TechZone Bracing Clip
Used For
Used to connect cross tees to the main beam of the continuous technical zone when no yoke is present.
7850
Pieces Per Carton
  • 30
Seismic Molding
Length
  • 144 in
Height
  • 7/8 in
Width
  • 1-1/8 in
7851
Pieces Per Carton
  • 30
Seismic Molding
Length
  • 120 in
Height
  • 7/8 in
Width
  • 1-1/8 in
